Product Introduction
| Material: | Alloy , Stainless |
| Capacity: | 1-10Mpa |
| Rated Output: | 1mV/V |
| Non Linearity: | ±0.5%F.S. |
| Hysteresis: | ±0.5%F.S. |
| Repeatability: | ±0.3%F.S. |
| Creep (30min): | ±0.5%F.S. |
| Zero Balance: | ±1.00%F.S. |
| Tem.Effect on Zero: | ±0.5%F.S./10℃ |
| Tem.Effect on Output: | ±0.5%F.S./10℃ |
| Input Impendance : | 350±5Ω |
| Out Impendance: | 350±3Ω |
| Insulation Impendance: | ≥5000MΩ |
| Excitation Voltage: | 10V (DC/AC) |
| Compensated Tem.Range: | -10℃~+50℃ |
| Service Tem.Range: | -20℃~+60℃ |
| Safe Overload Range: | 120%F.S. |
| Protection Class: | IP68 |
| Cable length: | 3m |
| Wire Code: | Red(Ex+) Black(Ex-) Green(Sig+) White(Sig-) |
| Net Weight: | 0.4kg |
